RFU MultiMode hub

1. Configuration → DMR Configuration — Color Code 1, enable DMR.
2. DMR Master / Network — TGIF_Network (or server tgif.network, port 62031).
3. Slot — use 2 for TG 2044 (our hub path is slot 2).
4. Talkgroups — add static RX group 2044 on slot 2, or dial 2044 from your radio.
5. Apply changes — reboot the hotspot if Pi-Star asks you to.

When you key up, you should appear on dash.radioforus.co.uk/xlx on module A.

1. Configuration → DMR Configuration — Color Code 1, enable DMR.
2. DMR Master / Network — FreeSTAR or server dmr.freestar.network, port 62031.
3. Slot — 2 (TG 2044 on our hub uses slot 2).
4. Talkgroups — static RX group 2044 on slot 2, or dial 2044 from the radio.
5. Apply changes — reboot if prompted.

When you key up, you should appear on dash.radioforus.co.uk/xlx on module B.

1. Configuration → DMR Configuration — Color Code 1, slot 2.
2. Enable XLX / XLX master (wording varies by Pi-Star build).
3. XLX host — dash.radioforus.co.uk or 86.175.155.115 (UDP port 62030 on the hub).
4. Reflector — XLX448.
5. Module — A for TGIF-style path, B for System X path.
6. Talkgroup — 2044 on slot 2.
7. Apply changes — reboot if prompted.

1. Configuration → YSF Configuration — enable YSF network.
2. XLX host — dash.radioforus.co.uk (UDP port 42000).
3. Reflector — XLX448, then link module A or B from the dashboard.
4. Apply changes — reboot if prompted.

1. Register at support.freestareverywhere.com with your amateur licence.
2. Sign in to your FreeSTAR Everywhere SIP or phone app.
3. Dial extension 8021 — phonebook name M9JAK RadioForUs Network Link.
4. Wait for the connected prompt, then *99 to transmit and # to unkey.
